J1N-0003NL image
Favorite
J1N-0003NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description FILTER UNIT, 80MM - More Details
PDF
/
Buying Options
Total Price: USD $86.54
Unit Price: USD $86.538491
≥1 USD $86.538491
≥195 USD $34.52927
≥495 USD $33.375231
≥1005 USD $32.805432
Inventory: 3082
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Contact Material Phosphor Bronze
Mount Panel, Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass

Technical

Operating Temperature 0°C~70°C
Packaging Tray
Published 2012
Series PULSEJACK? J1N
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type RJ45
Color Green
Applications 10/100/1000 Base-T, Power over Ethernet+ (PoE+)
Number of Rows 1
Gender Female
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Depth 34.04mm
Number of Positions Loaded 40
Contact Finish Gold
Number of Contacts 32
Number of Ports 4
LED Color Green - Green
Tab Direction Up
Number of Cores per Jack 9

Dimensions

Length 57.79mm
Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 0.480 12.19mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
