J1006F01P
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Modular Connectors / Ethernet Connectors 1X1TAB UP 4-CORE 673-J1006F21
PDF
/
Inventory: 8907
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Housing Material Thermoplastic
Shield Material Brass
Technical
Operating Temperature 0°C~70°C
Packaging Bulk
Published 2003
Series PULSEJACK? J1
Feature Board Guide
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Color Green, Yellow
Applications 10/100 Base-TX, AutoMDIX
Gender Female
Voltage - Rated 1.5kV
Voltage - Rated DC 1.5kV
Orientation 90° Angle (Right)
Shielding Shielded
Contact Finish Gold
Number of Ports 1
LED Color Green - Yellow
Tab Direction Up
Number of Cores per Jack 4
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Height Above Board 0.550 13.97mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
