J0011D01
RoHS
/
Package 100
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 1PORT 100 BASE-TX
PDF
/
Inventory: 7076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height Above Board 0.535 13.59mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Number of Cores per Jack 4
Tab Direction Down
LED Color Does Not Contain LED
Number of Ports 1
Contact Finish Gold
Current Rating 8mA
Shielding Shielded
Orientation 90° Angle (Right)
Gender Female
Applications 10/100 Base-TX, AutoMDIX
Color Black
Number of Positions 8
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Board Guide
Series PULSEJACK? J0
Published 2005
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Shield Material Brass
Housing Material Thermoplastic
Package / Case 100
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
