J00-0064
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Down STARJACK? J00 Non-RoHS Compliant 2005 Modular Connector (Type) 0C~70C 1.5kV 15.0muin 0.38mum
PDF
/
Inventory: 1556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass
Technical
Operating Temperature 0°C~70°C
Packaging Bulk
Published 2005
Series STARJACK? J00
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Color Black
Applications 10/100 Base-TX, AutoMDIX
Gender Female
Voltage - Rated DC 1.5kV
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Contacts 8
Number of Ports 1
LED Color Does Not Contain LED
Tab Direction Down
Number of Cores per Jack 4
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Height Above Board 0.545 13.84mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
