J00-0046NL image
Favorite
J00-0046NL image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 12 Terminal 1 Port Cat 5/Cat 6
PDF
/
Inventory: 9505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Applications 10/100 Base-TX, AutoMDIX
Additional Feature STARJACK, SHIELDED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Depth 21.59mm
Shell Finish NICKEL
Contact Finish Gold
Number of Contacts 8
Contact Gender FEMALE
Empty Shell NO
Number of Ports 1
LED Color Green - Yellow
Tab Direction Down
Number of Cores per Jack 4
Operating Temperature 0°C~70°C
Packaging Bulk
Published 2008
Series STARJACK? J00
JESD-609 Code e3

Dimensions

Length 16.26mm
Contact Finish Thickness 15.0μin 0.38μm
Height Above Board 0.545 13.84mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass
