5557804-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn Telephone/Telecom F 8 POS Solder RA Thru-Hole 8 Terminal 1 Port Tray Cat 3
PDF
/
Inventory: 956
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 76 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
PCB Mounting Orientation Right Angle
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2010
Feature Board Guide, Keyed
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Color Black
Orientation 90° Angle (Right)
Shielding Unshielded
Number of Positions Loaded 8
Current Rating 200mA
Contact Finish Gold
ELV Compliant
Element Configuration Single
Number of Ports 1
Circuit Application Signal
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Down
Keyed Yes
Dimensions
Height 13.386mm
Contact Finish Thickness 50.0μin 1.27μm
Contact Finish Thickness - Mating 1.27μm
Length - Tail 3.56mm
PCB Thickness 1.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Ratings Cat3
