555764-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connectors / Ethernet Connectors 8 SMD LO PRO R/A
PDF
/
Inventory: 5625
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Cat3
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant

Dimensions

Contact Finish Thickness 50.0μin 1.27μm
Length 15.37mm
Height 12.7mm

Technical

Keyed No
Preloaded Yes
Tab Direction Down
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Direction Down
Number of Ports 1
Element Configuration Single
Max Voltage Rating (AC) 150V
ELV Compliant
Housing Color Black
Number of Contacts 8
Contact Finish Gold
Number of Positions Loaded 8
Depth 18.17mm
Shielding Unshielded
Orientation 90° Angle (Right)
Pitch 1.27mm
Gender Female
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 8
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock, Solder Retention
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Housing Material Polyamide (PA), Nylon
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 3 Weeks
