5555153-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 3 Package/Tray
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.325624
≥1 USD $1.325624
≥10 USD $1.250588
≥100 USD $1.179802
≥500 USD $1.113023
≥1000 USD $1.050019
Inventory: 4095
Minimum: 1
-
+
Technical Details
Compliance
Ratings Cat3
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
PCB Thickness 1.57mm
Length - Tail 2.29mm
Contact Finish Thickness - Mating 1.27μm
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Width 17.91mm
Length 17.91mm
Height 12.7mm
Technical
Keyed No
Tab Direction Down
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Circuit Application Signal
Durability 750 Cycles
Number of Ports 1
Element Configuration Single
Max Voltage Rating (AC) 150V
ELV Compliant
Insulation Resistance 500000000Ohm
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Empty Shell NO
Body Breadth 0.495 inch
PCB Contact Pattern STAGGERED
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Shell Finish TIN
Current Rating 200mA
Number of Positions Loaded 8
Depth 18.42mm
Shielding Shielded
Orientation 90° Angle (Right)
Total Number of Contacts 8
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Gender Female
Color Black
Connector Type Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Panel Stops
JESD-609 Code e3
Published 2010
Packaging Tray
Operating Temperature -40°C~85°C
Physical
PCB Mounting Orientation Right Angle
Mounting Option 2 MOUNTING FLANGE
Mounting Option 1 LOCKING
Housing Material Polybutylene Terephthalate (PBT), Polyester
Shell Material COPPER ALLOY
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 11 Weeks
