5406903-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn Modular Jack F 12 POS 1.01mm Solder RA SMD 12 Terminal 2 Port T/R Cat 3
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.8656
≥1 USD $1.8656
≥10 USD $1.66672
≥100 USD $1.65792
≥500 USD $1.641024
≥1000 USD $1.505592
≥3000 USD $1.497162
Inventory: 5299
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Tail 1.52mm
Contact Finish Thickness - Mating 1.27μm
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Height 12.95mm
Technical
Keyed No
Tab Direction Up
LED Color Does Not Contain LED
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
Circuit Application Signal
Number of Ports 2
Element Configuration Single
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 500000000Ohm
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Operating Temperature (Min) -40°C
Operating Temperature (Max) 70°C
PCB Contact Pattern RECTANGULAR
Number of Contacts 12
Body Length or Diameter 0.95 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Shielding Shielded
Orientation 90° Angle (Right)
Pitch 1.01mm
Subcategory Telecom and Datacom Connectors
Gender Female
Number of Rows 1
Color Black
Number of Positions 8
Connector Type Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Panel Stops
Published 2006
Packaging Tape & Reel (TR)
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mounting Type Surface Mount
Contact Material Copper Alloy
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 11 Weeks
