406525-1
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn RJ-45 F 8 POS 2.04mm Solder RA Thru-Hole 8 Terminal 1 Port Tray Cat 5
PDF
/
Buying Options
Total Price: USD $13.15
Unit Price: USD $13.14515
≥1 USD $13.14515
≥10 USD $10.78535
≥100 USD $10.4481
≥500 USD $10.1118
≥1000 USD $9.77455
Inventory: 1353
Minimum: 1
-
+
Technical Details
Compliance
Ratings Cat5
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
PCB Thickness 1.57mm
Length - Tail 2.54mm
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Length 15.75mm
Technical
Keyed No
Tab Direction Up
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Withdrawl Force-Min 22.24 N
Insertion Force-Max 22.24 N
Durability 750 Cycles
Number of Ports 1
Element Configuration Single
Max Voltage Rating (AC) 150V
ELV Compliant
Insulation Resistance 500000000Ohm
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.52 inch
PCB Contact Pattern STAGGERED
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Positions Loaded 8
Depth 15.24mm
Shielding Unshielded
Orientation 90° Angle (Right)
Total Number of Contacts 8
Pitch 2.04mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Additional Feature LOW PROFILE, SIDE ENTRY, SHIELDED
Color Black
Connector Type Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Board Guide
JESD-609 Code e0
Published 2004
Packaging Tray
Operating Temperature -40°C~85°C
Physical
PCB Mounting Orientation Right Angle
Mounting Option 1 LOCKING
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 25 Weeks
Alternative Model
