2170136-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn RJ-45 F 8 POS 1.27mm Solder RA SMD 8 Terminal 1 Port T/R
PDF
/
Inventory: 2900
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mounting Type Surface Mount
Housing Material Polyamide (PA9T), Nylon 9T, Glass Filled
PCB Mounting Orientation Right Angle
Technical
Packaging Bulk
Published 2007
Series A-RJ45
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Number of Positions 8
Color Black
Number of Rows 1
Gender Female
Pitch 1.27mm
Orientation 90° Angle (Right)
Shielding Shielded
Number of Positions Loaded 8
Current Rating 1A
Contact Finish Gold
Number of Contacts 8
Housing Color Black
ELV Compliant
Element Configuration Single
Number of Ports 1
Circuit Application Signal
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Down
Keyed No
Dimensions
Height 13mm
Contact Finish Thickness 30.0μin 0.76μm
Contact Finish Thickness - Mating 760 nm
Length - Tail 2.4mm
PCB Thickness 1.6mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
