1364173-5
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connectors / Ethernet Connectors INV MJ 1X2 PNL GRND LED (G/G)
PDF
/
Inventory: 9506
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Cat5
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Length - Tail 2.54mm
Plating Thickness 1.27μm
Contact Finish Thickness 50.0μin 1.27μm
Technical
Keyed No
Tab Direction Up
LED Color Green - Green
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Durability 750 Cycles
Number of Ports 2
ELV Compliant
Insulation Resistance 500000000Ohm
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.55 inch
PCB Contact Pattern STAGGERED
Number of Contacts 16
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Number of Rows 1
Color Black
Number of Positions 8
Connector Type Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Board Guide
JESD-609 Code e0
Published 2007
Packaging Tray
Operating Temperature -40°C~85°C
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Shell Material COPPER ALLOY
Mounting Type Through Hole
Mount Panel
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 15 Weeks
