1-338086-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn RJ-14 F 6 POS 1.27mm Solder ST SMD 4 Terminal 1 Port T/R Cat 3
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.8512
≥1 USD $2.8512
≥10 USD $2.54144
≥100 USD $2.528416
≥500 USD $2.502368
≥1000 USD $2.256056
Inventory: 250
Minimum: 1
-
+
Technical Details
Compliance
Ratings Cat3
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
PCB Thickness 1.57mm
Length - Tail 2.5mm
Length 13.35mm
Height 12.7mm
Technical
Keyed No
Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 6p4c (RJ11, RJ14)
Direction User Selectable
Circuit Application Signal
Number of Ports 1
Element Configuration Single
Max Current Rating 1.5A
Max Voltage Rating (AC) 150V
ELV Compliant
Housing Color Black
Number of Contacts 6
Contact Finish Gold
Number of Positions Loaded 4
Depth 14mm
Shielding Unshielded
Orientation Vertical
Pitch 1.27mm
Number of Rows 1
Color Black
Number of Positions 6
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Solder Retention
Published 2012
Packaging Tape & Reel (TR)
Physical
Package Quantity 300
PCB Mounting Orientation Vertical
Housing Material Polyamide (PA9T), Nylon 9T, Glass Filled
Mounting Type Surface Mount
Contact Plating Gold, Nickel
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
