5406554-4
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 9055
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Tail 2.54mm
Contact Finish Thickness - Mating 1.27μm
Plating Thickness 1.27μm
Height 13.35mm
Technical
Keyed No
Direction Up
Circuit Application Signal
Durability 750 Cycles
Number of Ports 6
ELV Compliant
Body/Shell Style JACK
Insulation Resistance 500000000Ohm
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.55 inch
PCB Contact Pattern STAGGERED
Number of Contacts 48
Body Length or Diameter 3.79 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Shell Finish NICKEL TIN
Current Rating 1.5A
Shielding Shielded
Orientation Right Angle
Pitch 2.03mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 8
Connector Type TELECOM AND DATACOM CONNECTOR
ECCN Code EAR99
Termination Solder
JESD-609 Code e3
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Shell Material COPPER-ZINC ALLOY
Mount Panel
Contact Plating Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
