406552-1
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Buying Options
Total Price: USD $4.56
Unit Price: USD $4.56475
≥1 USD $4.56475
≥10 USD $3.7449
≥100 USD $3.62805
≥500 USD $3.5112
≥1000 USD $3.39435
Inventory: 114
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Panel
Shell Material COPPER ALLOY
Housing Material Thermoplastic
PCB Mounting Orientation Right Angle
Technical
JESD-609 Code e0
Pbfree Code no
Termination Solder
ECCN Code EAR99
Connector Type TELECOM AND DATACOM CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Black
Gender Female
Voltage - Rated 150V
Subcategory Telecom and Datacom Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.04mm
Orientation Right Angle
Shielding Shielded
Depth 15.75mm
Number of Positions Loaded 32
Current Rating 1.5A
Shell Finish NICKEL
Reference Standard UL
Reliability COMMERCIAL
Number of Contacts 8
PCB Contact Pattern STAGGERED
Body Breadth 0.55 inch
Empty Shell NO
Contact Style TELCOM, MODULAR
Contact Resistance 10mOhm
Insulation Resistance 500000000Ohm
Body/Shell Style JACK
ELV Compliant
Max Voltage Rating (AC) 150V
Dielectric Withstanding Voltage 900VAC V
Number of Ports 4
Durability 750 Cycles
Keyed No
Dimensions
Length 64.77mm
Plating Thickness 3.81μm
Length - Tail 2.54mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
