106176-1
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
CONN MOD JACK 4P4C VERT UNSHLD
PDF
/
Inventory: 4739
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 50μin
Height 15.7mm
Technical
Keyed No
Preloaded Yes
Direction User Selectable
Durability 750 Cycles
Number of Ports 1
Element Configuration Single
ELV Compliant
Body/Shell Style JACK
Contact Resistance 20mOhm
Contact Style TELCOM, MODULAR
Contact Gender MALE
Body Breadth 0.709 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 4
Reliability COMMERCIAL
Reference Standard UL, CSA
Shielding Unshielded
Orientation Vertical
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 70°C
Connector Type TELECOM AND DATACOM CONNECTOR
Termination Solder
Pbfree Code yes
Packaging Tape & Reel (TR)
Physical
Housing Material Nylon
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
