MODS-D-8P8C-L-S-SM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn Modular Jack F 8 POS 1.27mm Solder RA SMD 8 Terminal 1 Port Tray Cat 3
PDF
/
Inventory: 4011
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount
Shell Material COPPER ALLOY
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Technical
Operating Temperature -25°C~90°C
Packaging Tray
Published 2010
Series MODS-D
JESD-609 Code e3
Feature Board Lock, Panel Stops
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Jack
Gender Female
Subcategory Telecom and Datacom Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Orientation 90° Angle (Right)
Shielding Shielded
Depth 18.4mm
Shell Finish NICKEL
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number of Contacts 8
PCB Contact Pattern RECTANGULAR
Body Breadth 0.535 inch
UL Flammability Code 94V-0
Empty Shell NO
Contact Style TELCOM, MODULAR
Contact Resistance 20mOhm
Max Voltage Rating (AC) 120V
Number of Ports 1
Durability 500 Cycles
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Length 17.8mm
Contact Finish Thickness 15.0μin 0.38μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Ratings Cat3
