E6688-120212-L
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 1378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Edge, Surface Mount
Mounting Type Board Edge, Cutout; Surface Mount
Shell Material BRASS
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2006
JESD-609 Code e3
Feature Board Guide, Solder Retention
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.02mm
Orientation 90° Angle (Right)
Shielding Shielded
Contact Finish Gold
Number of Contacts 8
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 1
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Contact Finish Thickness 6.00μin 0.152μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
