E5J88-24CJ25-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 8188
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Shell Material GLASS FILLED POLYAMIDE
Housing Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2006
JESD-609 Code e3
Feature Board Guide, Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Jack
Number of Rows 1
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.04mm
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Depth 15.7mm
Contact Finish Gold
Number of Contacts 32
Mating Information MULTIPLE MATING PARTS AVAILABLE
Housing Color Black
Empty Shell NO
Contact Resistance 30mOhm
Max Voltage Rating (AC) 125V
Max Current Rating 1.5A
Number of Ports 4
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Green - Green
Tab Direction Up
Dimensions
Length 63.8mm
Contact Finish Thickness 50.0μin 1.27μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
