Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Inventory: 9743
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 6.00μin 0.152μm

Technical

Tab Direction Up
LED Color Green - Green
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Number of Ports 4
Empty Shell NO
Contact Gender FEMALE
Contact Finish Gold
Shell Finish NICKEL
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Total Number of Contacts 32
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e4
Published 2012
Packaging Tray
Operating Temperature 0°C~70°C

Physical

Housing Material Polyamide (PA FR52), Nylon FR52
Shell Material COPPER ALLOY
Mounting Type Through Hole
Contact Material Phosphor Bronze
