E5J88-12LJ23-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 3554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Cat3
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Technical
Tab Direction Up
LED Color Yellow - Green
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Number of Ports 1
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Number of Contacts 8
Contact Finish Gold
Shell Finish NICKEL
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e4
Published 2012
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Housing Material Polyamide (PA FR52), Nylon FR52
Shell Material COPPER ALLOY
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
