RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Inventory: 3601
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Cat3
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Tab Direction Up
LED Color Yellow - Green
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Number of Ports 1
Empty Shell NO
UL Flammability Code 94V-0
Number of Contacts 8
Contact Finish Gold
Shell Finish NICKEL
Shielding Shielded
Orientation 90° Angle (Right)
Pitch 2.04mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e4
Published 2006
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Housing Material Polyamide (PA FR52), Nylon FR52
Shell Material COPPER ALLOY
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
