RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.36808
≥100 USD $2.242592
≥500 USD $2.19054
≥1000 USD $2.086154
≥3000 USD $1.825428
Inventory: 3613
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 9 Weeks

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Shell Material GLASS FILLED POLYAMIDE
Housing Material Polyamide (PA), Nylon, Glass Filled

Technical

Operating Temperature 0°C~70°C
Packaging Tray
JESD-609 Code e4
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation 90° Angle (Right)
Shielding Unshielded
Depth 27.7mm
Contact Finish Gold
Number of Contacts 16
UL Flammability Code 94V-0
Empty Shell NO
Contact Resistance 50mOhm
Max Voltage Rating (AC) 125V
Max Current Rating 1.5A
Number of Ports 2
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Up and Down

Dimensions

Length 16.5mm
Contact Finish Thickness 15.0μin 0.38μm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Ratings Cat3
