E5564-20A522-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 7901
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Shell Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2012
JESD-609 Code e4
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Number of Rows 1
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation 90° Angle (Right)
Shielding Unshielded
Contact Finish Gold
Number of Contacts 4
Empty Shell NO
Number of Ports 2
Number of Positions/Contacts 6p4c (RJ11, RJ14)
LED Color Does Not Contain LED
Tab Direction Up
Dimensions
Contact Finish Thickness 6.00μin 0.152μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings Cat3
