E5388-EH05Y2-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
SIDE ENTRY Modular Connector Jack
PDF
/
Inventory: 6378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Surface Mount
Mounting Type Surface Mount
Housing Material Polyamide (PA FR52), Nylon FR52
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Additional Feature SIDE ENTRY
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.27mm
Orientation 90° Angle (Right)
Shielding Unshielded
Depth 18.1mm
Contact Finish Gold
Number of Contacts 8
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Black
Empty Shell NO
Contact Resistance 35mOhm
Max Voltage Rating (AC) 125V
Max Current Rating 1.5A
Number of Ports 1
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Length 18.7mm
Contact Finish Thickness 6.00μin 0.152μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings Cat3
