E5364-00A512-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 1823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2006
JESD-609 Code e4
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Number of Rows 1
Gender Female
Subcategory Telecom and Datacom Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation 90° Angle (Right)
Shielding Unshielded
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number of Contacts 4
PCB Contact Pattern STAGGERED
Empty Shell NO
Body Depth 0.07 inch
Contact Style TELCOM, MODULAR
Contact Resistance 30mOhm
Number of Ports 2
Durability 750 Cycles
Insulator Color BLACK
Number of Positions/Contacts 6p4c (RJ11, RJ14)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Contact Finish Thickness 6.00μin 0.152μm
Plating Thickness 6μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings Cat3
