E52D8-R20B44-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
TOP ENTRY Modular Connector Jack
PDF
/
Inventory: 7656
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Shell Material GLASS FILLED POLYESTER
Housing Material Polyester, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tray
JESD-609 Code e4
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Gender Female
Additional Feature TOP ENTRY
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Contacts 8
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 1
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Does Not Contain LED
Tab Direction User Selectable
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
