Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Inventory: 3545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Shell Material BRASS
Housing Material Polyamide (PA FR50), Nylon FR50

Technical

Operating Temperature 0°C~70°C
Packaging Tray
Published 2006
JESD-609 Code e4
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Vertical
Shielding Shielded
Shell Finish NICKEL
Contact Finish Gold
Number of Contacts 8
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 1
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
LED Color Yellow - Green
Tab Direction User Selectable

Dimensions

Contact Finish Thickness 50.0μin 1.27μm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
