E5288-32G145-L
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connector Jack
PDF
/
Inventory: 3811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 50μin
Contact Finish Thickness 50.0μin 1.27μm
Technical
Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Insulator Color BLACK
Durability 750 Cycles
Number of Ports 8
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Body Depth 0.65 inch
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number of Contacts 64
Body Length or Diameter 4.362 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shielding Shielded
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Telecom and Datacom Connectors
Gender Female
Number of Rows 1
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
JESD-609 Code e4
Published 2012
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Housing Material Polyester, Glass Filled
Shell Material GLASS FILLED POLYESTER
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
