Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Buying Options
Total Price: USD $1.5
Unit Price: USD $1.496
≥1 USD $1.496
≥10 USD $1.30416
≥100 USD $1.248544
≥500 USD $1.220736
≥1000 USD $1.165208
≥3000 USD $1.054275
Inventory: 2945
Minimum: 1
-
+

Technical Details

Compliance

Ratings Cat3
RoHS Status RoHS Compliant

Dimensions

Plating Thickness 3μin
Contact Finish Thickness 3.00μin 0.076μm

Technical

Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Insulator Color BLACK
Durability 750 Cycles
Number of Ports 1
Contact Resistance 30mOhm
Contact Style TELCOM, MODULAR
Body Depth 0.65 inch
Contact Gender MALE
Body Breadth 0.657 inch
PCB Contact Pattern STAGGERED
Body Length or Diameter 0.63 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish TIN
Terminal Pitch 2.54mm
Shielding Shielded, EMI Finger
Orientation Vertical
Total Number of Contacts 8
Subcategory Telecom and Datacom Connectors
HTS Code 8536.69.40.30
Connector Type Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Board Mounting Option HOLE .064-.072
Mounting Option 1 LOCKING
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 9 Weeks
