E5288-300042-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
TOP ENTRY Modular Connector Jack
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
≥10 USD $0.5016
≥100 USD $0.484
Inventory: 3239
Minimum: 1
-
+
Technical Details
Compliance
Ratings Cat3
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 6.00μin 0.152μm
Technical
Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Number of Ports 1
Empty Shell NO
UL Flammability Code 94V-0
Number of Contacts 8
Contact Finish Gold
Shielding Unshielded
Orientation Vertical
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature TOP ENTRY
Gender Female
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock
JESD-609 Code e4
Published 2012
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Housing Material Polyester, Glass Filled
Shell Material GLASS FILLED POLYESTER
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
