Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Modular Connector Jack
PDF
/
Inventory: 975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Technical

Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 4p4c (RJ9, RJ10, RJ22)
Number of Ports 1
Empty Shell NO
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 4
Contact Finish Gold
Shielding Unshielded
Orientation Vertical
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Panel Stops
JESD-609 Code e4
Published 2006
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Shell Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
