43202-8917
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connectors / Ethernet Connectors RA 8/8 RJ45 low profile
PDF
/
Buying Options
Total Price: USD $2.1
Unit Price: USD $2.098061
≥1 USD $2.098061
≥10 USD $1.979303
≥100 USD $1.867263
≥500 USD $1.761576
≥1000 USD $1.661858
Inventory: 7475
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass, Bronze
Contact Plating Gold
Mount Through Hole
Housing Material Nylon
Technical
Published 2012
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type RJ45
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Black
Gender Female
Subcategory Telecom and Datacom Connectors
Voltage - Rated DC 125V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 8
Orientation Right Angle
Shielding Shielded
Depth 18.64mm
Number of Positions Loaded 8
Current Rating 1.5A
Shell Finish NICKEL
Reference Standard UL, CSA
Reliability COMMERCIAL
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.476 inch
UL Flammability Code 94V-0
Empty Shell NO
Contact Style TELCOM, MODULAR
Contact Resistance 10mOhm
Insulation Resistance 500000000Ohm
Body/Shell Style JACK
Number of Ports 1
Durability 500 Cycles
Direction Down
Dimensions
Length 18.35mm
Plating Thickness 50μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
