15-43-8584
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
STAGGERED CONFIGURATION Modular Connector Jack
PDF
/
Inventory: 6577
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 50μin
Technical
Direction Down
Durability 500 Cycles
Number of Ports 1
Body/Shell Style JACK
Insulation Resistance 500000000Ohm
Contact Style TELCOM, MODULAR
Empty Shell NO
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Body Breadth 0.63 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Length or Diameter 0.6 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Current Rating 1.5A
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Shielding Unshielded
Total Number of Contacts 4
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated DC 125V
Subcategory Telecom and Datacom Connectors
Additional Feature STAGGERED CONFIGURATION
Gender Female
Color Black
Number of Positions 8
Connector Type TELECOM AND DATACOM CONNECTOR
ECCN Code EAR99
Termination Solder
Published 2004
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
