0855135010

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Conn RJ-12 F 6 POS 1.27mm Solder ST SMD 6 Terminal 1 Port Embossed T/R Cat 3
PDF
/
Buying Options
Total Price: USD $1.25
Unit Price: USD $1.246673
≥1 USD $1.246673
≥10 USD $1.176106
≥100 USD $1.109533
≥500 USD $1.046728
≥1000 USD $0.987477
Inventory: 5398
Minimum: 1
-
+

Technical Details

Compliance

Ratings Cat3
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness Flash
Length 13.21mm

Technical

Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
Direction User Selectable
Max Voltage Rating (DC) 125V
Number of Ports 1
Empty Shell NO
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 6
Contact Finish Gold
Current Rating 1.5A
Depth 15.08mm
Shielding Unshielded
Orientation Vertical
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature STANDARD:RJ45
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Solder Retention
Series 85513
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Shell Material POLYETHYLENE
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 25 Weeks
