0432498920

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Conn Telephone/Telecom F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 3/Cat 4 Tray
PDF
/
Inventory: 3353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Cat4
RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 15.24mm

Technical

Tab Direction Down
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Direction Down
Number of Ports 1
Max Voltage Rating (AC) 150V
Housing Color Black
Number of Contacts 8
Contact Finish Gold
Number of Positions Loaded 8
Depth 20.57mm
Shielding Shielded
Orientation 90° Angle (Right)
Pitch 2.54mm
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock
Series 43249
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Housing Material Polyamide (PA), Nylon, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Phosphor Bronze
