0432236101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Conn RJ-11 RCP 12 POS 2.54mm Solder RA Thru-Hole 12 Terminal 2 Port Tray Cat 3/Cat 4
PDF
/
Buying Options
Total Price: USD $2.81
Unit Price: USD $2.8072
≥1 USD $2.8072
≥10 USD $2.46928
≥100 USD $1.964494
≥500 USD $1.571574
≥1000 USD $1.515448
Inventory: 884
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Shell Material POLYETHYLENE
Housing Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series 43223
Feature Board Lock
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Number of Rows 1
Additional Feature 6 PORTS 6 CONTACTS EACH, LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 6
Orientation 90° Angle (Right)
Shielding Unshielded
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
UL Flammability Code 94V-0
Empty Shell NO
Number of Ports 2
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Cat4
