0432236004

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description Conn RJ-11 F 18 POS 2.54mm Solder RA Thru-Hole 18 Terminal 3 Port Tray Cat 3
PDF
/
Inventory: 6942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Cat4
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Contact Finish Thickness 50.0μin 1.27μm
Length 38.94mm

Technical

Tab Direction Down
LED Color Does Not Contain LED
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
Number of Ports 3
Max Voltage Rating (AC) 150V
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 18
Contact Finish Gold
Current Rating 1.5A
Depth 20.57mm
Shielding Unshielded
Orientation 90° Angle (Right)
Pitch 1.02mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature 4 PORTS 6 CONTACTS EACH, LOW PROFILE
Gender Female
Number of Rows 1
Color Black
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Lock, Panel Stops
Series 43223
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Housing Material Polyamide (PA), Nylon, Glass Filled
Shell Material POLYETHYLENE
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
