0428784408
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Modular Connectors / Ethernet Connectors ModJack 125 Flush LoPro W/O Clip 4/2
PDF
/
Inventory: 3087
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Cat3
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Length 13.97mm
Technical
Tab Direction User Selectable
LED Color Does Not Contain LED
Number of Positions/Contacts 4p2c (RJ9)
Direction User Selectable
Number of Ports 1
Max Voltage Rating (AC) 150V
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 1.5A
Reach Compliance Code unknown
Number of Positions Loaded 2
Depth 15.88mm
Shielding Unshielded
Orientation Vertical
Total Number of Contacts 2
Pitch 1.02mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Gender Female
Color Black
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Lock, Panel Stops
Series 42878
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Housing Material Polyester, Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
