A-2004-1-3-LP/S-R
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
Down RoHS Compliant COMMERCIAL UL Modular Connector (Type) 500Cycles 20mOhm -40C~85C 0.535inch
PDF
/
Inventory: 3267
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT)
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2011
Feature Board Lock, Panel Stops
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Jack
Subcategory Telecom and Datacom Connectors
Total Number of Contacts 6
Orientation 90° Angle (Right)
Shielding Shielded
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
PCB Contact Pattern STAGGERED
Body Breadth 0.535 inch
Contact Gender MALE
Body Depth 0.724 inch
Contact Style TELCOM, MODULAR
Contact Resistance 20mOhm
Insulation Resistance 500000000Ohm
Number of Ports 1
Durability 500 Cycles
Insulator Color BLACK
Number of Positions/Contacts 6p6c (RJ11, RJ12, RJ14, RJ25)
LED Color Does Not Contain LED
Tab Direction Down
Dimensions
Contact Finish Thickness 50.0μin 1.27μm
Plating Thickness 50μin
Compliance
RoHS Status RoHS Compliant
