AOM-6742L
RoHS
/
Package /
Category Audio Products / Microphones
Description
MICROPHONE COND ANALOG OMNI
PDF
/
Inventory: 6895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height (Max) 0.272 6.90mm
Height 6.9mm
Diameter 9.7mm
Technical
S/N Ratio 60dB
Port Location Top
Sensitivity -42dB ±3dB
Voltage Range 1.5V~10V
Direction Omnidirectional
Current - Supply 500μA
Impedance 2.2kOhms
Operating Supply Current 500μA
Operating Supply Voltage 1.5V
Output Type Analog
Depth 6.7mm
Voltage - Rated 1.5V
Resistance 2.2kOhm
Type Electret Condenser
Termination Solder Pads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.382Dia 9.70mm
Series AOM
Packaging Bulk
Physical
Shape Circular
