EM-24059-052
RoHS
/
Package /
Category Audio Products / Microphones
Description
Microphones Omni-Directional Microphone
PDF
/
Inventory: 8635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.090 2.28mm
Technical
Port Location Side
Sensitivity -52.5dB ±4dB @ 74dB SPL
Frequency Range 100Hz~10kHz
Direction Omnidirectional
Impedance 4.4kOhm
Output Type Analog
Frequency 6.4kHz
Current Rating 50μA
Depth 2.21mm
Voltage - Rated 1.3V
Type Electret Condenser
Termination Solder Pads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.141Lx0.141W 3.57mmx3.57mm
Series EM
Packaging Bulk
Physical
Shape Square
