EK-28522-C25
RoHS
/
Package /
Category Audio Products / Microphones
Description
Microphones 5.56 X 3.98 X 2.21MM -54 SENS, 12S PORT
PDF
/
Buying Options
Total Price: USD $27.81
Unit Price: USD $27.809848
≥1 USD $27.809848
≥200 USD $11.096631
≥500 USD $10.72508
≥1000 USD $10.542587
Inventory: 6422
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.089 2.26mm
Technical
Port Location Side
Sensitivity -54dB ±2dB @ 74dB SPL
Frequency Range 100Hz~5.5kHz
Voltage Range 0.9V~10V
Direction Omnidirectional
Impedance 4.4kOhm
Output Type Analog
Frequency 5.5kHz
Current Rating 50μA
Depth 2.21mm
Voltage - Rated 1.3V
Type Electret Condenser
Termination Solder Pads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Series EK
Published 2012
Packaging Bulk
Physical
Shape Rectangular
