EK-27659-C05
RoHS
/
Package /
Category Audio Products / Microphones
Description
Electret Condenser Solder Pads Analog Rectangular Electret Condenser Microphone 100Hz~10kHz -53dB ±2dB @ 74dB SPL 4.4kOhm 50muA
PDF
/
Inventory: 4901
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.089 2.26mm
Technical
Port Location Side
Sensitivity -53dB ±2dB @ 74dB SPL
Frequency Range 100Hz~10kHz
Direction Omnidirectional
Impedance 4.4kOhm
Operating Supply Voltage 1.3V
Output Type Analog
Current Rating 50μA
Depth 2.21mm
Voltage - Rated 1.3V
Type Electret Condenser
Termination Solder Pads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Series EK
Published 2013
Packaging Bulk
Physical
Shape Rectangular
