EK-27263-A21
RoHS
/
Package /
Category Audio Products / Microphones
Description
Electret Condenser Solder Pads Analog Rectangular Electret Condenser Microphone 6kHz 100Hz~10kHz -53dB ±2dB @ 74dB SPL 4.4kOhm
PDF
/
Inventory: 9870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shape Rectangular
Technical
Packaging Bulk
Published 2013
Series EK
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Pads
Type Electret Condenser
Voltage - Rated 1.3V
Depth 2.21mm
Current Rating 50μA
Frequency 6kHz
Output Type Analog
Impedance 4.4kOhm
Direction Omnidirectional
Frequency Range 100Hz~10kHz
Sensitivity -53dB ±2dB @ 74dB SPL
Port Location Side
Dimensions
Height (Max) 0.089 2.26mm
Compliance
RoHS Status RoHS Compliant
