EK-23103-000
RoHS
/
Package /
Category Audio Products / Microphones
Description
Microphones 5.56 X 3.98 X 2.21MM -53 SENS, 0KPL PORT
PDF
/
Buying Options
Total Price: USD $33.88
Unit Price: USD $33.878072
≥1 USD $33.878072
≥200 USD $13.517618
≥500 USD $13.065981
≥1000 USD $12.842788
Inventory: 3009
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Shape Rectangular
Technical
Packaging Bulk
Published 2013
Series EK
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Pads
Type Electret Condenser
Voltage - Rated 1.3V
Depth 2.21mm
Current Rating 50μA
Output Type Analog
Operating Supply Voltage 1.3V
Impedance 4.4kOhm
Direction Omnidirectional
Voltage Range 0.9V~10V
Frequency Range 100Hz~8kHz
Sensitivity -53dB ±2dB @ 74dB SPL
Port Location Top
Dimensions
Height (Max) 0.089 2.26mm
Compliance
RoHS Status RoHS Compliant
