EA-21867-000
RoHS
/
Package /
Category Audio Products / Microphones
Description
Microphones 5.56 X 3.98 X 2.21MM -54 SENS, 12S PORT
PDF
/
Inventory: 5823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shape Rectangular
Technical
Packaging Bulk
Published 2012
Series EA
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Pads
Type Electret Condenser
Voltage - Rated 1.3V
Depth 2.21mm
Current Rating 50μA
Frequency 5.3kHz
Output Type Analog
Impedance 3.5kOhm
Direction Omnidirectional
Frequency Range 1kHz~5.3kHz
Sensitivity -54dB ±4dB
Port Location Side
Dimensions
Height (Max) 0.089 2.26mm
Compliance
RoHS Status RoHS Compliant
