CMC-5044PF-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Microphones
Description
6.0 mm, Omnidirectional, PCB Mount, 2.0 Vdc, Electret Condenser Microphone
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.6776
≥100 USD $0.627968
≥500 USD $0.591536
≥1000 USD $0.556336
≥3000 USD $0.516771
Inventory: 1253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Solder
Shape Circular
Technical
Packaging Bulk
Published 2011
Size / Dimension 0.236Dia 6.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Type Electret Condenser
Voltage - Rated 2V
Output Type Analog
Operating Supply Current 500μA
Impedance 2.2kOhm
Direction Omnidirectional
Voltage Range 2V~10V
Frequency Range 100Hz~20kHz
Sensitivity -44dB ±3dB @ 94dB SPL
Port Location Top
S/N Ratio 56dB
Dimensions
Height 5.2mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
