MC22FF751J-TF
RoHS
RoHS compliant
RoHS compliantPackage 2220 (5750 Metric)
Category Capacitors / Mica and PTFE Capacitors
Description
MC 2220 (5750Metric) Mica Capacitor 0.224Lx0.197W 5.70mmx5.00mm 25ppm/C ±5% 750pF
PDF
/
Buying Options
Total Price: USD $8.13
Unit Price: USD $8.126851
≥1 USD $8.126851
≥200 USD $3.242863
≥500 USD $3.135205
≥1000 USD $3.081376
Inventory: 9649
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2220 (5750 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Mica
Weight 480.014126mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2013
Series MC
Size / Dimension 0.224Lx0.197W 5.70mmx5.00mm
Tolerance ±5%
JESD-609 Code e3
Feature RF, High Q, Low Loss
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient 25 ppm/°C
Terminal Finish Tin (Sn)
HTS Code 8532.29.00.20
Capacitance 750pF
Voltage - Rated DC 1kV
Packing Method TR
Case Code (Metric) 5750
Case Code (Imperial) 2220
Multilayer Yes
Rated (DC) Voltage (URdc) 1000V
Dissipation Factor 0.1 %
Dimensions
Height 4mm
Height Seated (Max) 0.157 4.00mm
Length 5.7mm
Width 5mm
Compliance
RoHS Status ROHS3 Compliant
