CMR05E220JPDM
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Capacitors / Mica and PTFE Capacitors
Description
CMR Radial Mica Capacitor 0.449Lx0.169W 11.40mmx4.30mm -20/+100ppm/Cel ppm/C ±5% 22pF
PDF
/
Buying Options
Total Price: USD $20.71
Unit Price: USD $20.710998
≥1 USD $20.710998
≥190 USD $8.264706
≥494 USD $7.987684
≥988 USD $7.851142
Inventory: 2015
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial
Surface Mount NO
Terminal Shape WIRE
Dielectric Material Mica
Technical
Operating Temperature -55°C~150°C
Packaging Bulk
Published 2015
Series CMR
Size / Dimension 0.449Lx0.169W 11.40mmx4.30mm
Tolerance ±5%
JESD-609 Code e0
Feature General Purpose
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient -20/+100ppm/Cel ppm/°C
Terminal Finish Tin/Lead (Sn60Pb40)
Voltage - Rated 500V
HTS Code 8532.29.00.20
Capacitance 22pF
Depth 4.3mm
Military Standard MIL-PRF-39001
Lead Pitch 5.7mm
Lead Spacing 0.224 5.70mm
Rated (DC) Voltage (URdc) 500V
Lead Diameter 600 μm
Size Code 4517
Dimensions
Height Seated (Max) 0.358 9.10mm
Length 11.4mm
Compliance
RoHS Status ROHS3 Compliant
